Suez Canal 1973 war maps

Recommended Posts

Egyptian offensive plan:



1527da_e381116657ca43ef8483b231856b551d~





Phase 1 - Operation Badr:

Under the SAM umbrella from the western bank, 5 Infantry divisions and two independent infantry brigades cross the Suez Canal (180 meters wide, 163 kms long) in between the Israeli Bar-Lev front-line fortified strongholds (blue circles), advance east across the whole front and take the Israeli second-line posts (blue squares) on the higher terrain, 10-12 kms east of the canal, within a day or two.



Northern sector:

135th independent infantry brigade crosses the canal near Ras Al-Ash - At-Tina, south of Port Fuad (the northern 10 kms of the eastern bank were already in Egyptian hands before the war). Note that driving off-road in the At-Tina Plain - Sabkhat Al-Mallaha area is impossible due to the salt marsh saline clay soil.



2nd field army:

18th infantry division, reinforced with the elite 15th independent armored brigade (T-62s), crosses the canal near Al-Qantara - Al-Ballah Island.

2nd infantry division, reinforced with the 24th armored brigade (from the 23rd mechanized infantry division), crosses the canal near Al-Firdan - Al-Firdan Bridge, between Al-Ballah Island and Al-Ismailia.

16th infantry division, reinforced with the 14th armored brigade (from the 21st armored division), crosses the canal near Serapeum - Deversoir, between Al-Ismailia and the Greater Bitter Lake.



3rd field army:

130th marine brigade crosses the Bitter Lakes by its amphibious AFVs (BTR-50/OT-62, PT-76, BRDM-2) at Kibrit Peninsula (this move is not shown on the map).

7th infantry division, reinforced with the elite 25th independent armored brigade (T-62s), crosses the canal near Ash-Shallufa, south of the Little Bitter Lake.

19th infantry division, reinforced with the 22nd armored brigade (from the 6th mechanized infantry division), crosses the canal near Al-Kubri - Suez.

1st mechanized infantry brigade (from the 6th mechanized infantry division) crosses the canal following the 19th infantry division and heads south on the eastern Suez Bay coastline road towards Ras Misalla, Ras Sudr and At-Tur, teaming-up with the commandos along the way.



Unmarked on the map: heliborne commandos land at Tell Al-Farama - Baluza - Rumani, NW of Jabal Umm Marjum, at Bir Umm Jarf - Ras Al-Jundi and at Abu Rudays - Ras Sharatib. Naval commandos land at Ras Sudr (after sailing from Bir Adib), at Ras Mal'ab - Abu Znayma and at Abu Rudays - Ras Sharatib (after sailing from Ras Za'afrana).





Phase 2 - The Operational Halt:

Egyptian infantry divisions (heavily reinforced with armor, AT weapons and artillery) entrench themselves in at the eastern bank and repel IDF reserve armor assaults for 7 days. The Egyptians deploy SAM batteries at the eastern bank.





Phase 3 - the major armor offensive (optional, if IDF tank and fighter aircraft losses are heavy enough):

Egyptian armored and mechanized infantry divisions cross the Suez Canal, assault and take central Sinai within 4-5 days.



2nd field army:

15th independent armored brigade, along with 18th infantry division forces, advances to Baluza, Rumani and Misfaq.

23rd mechanized infantry and 21st armored divisions cross the canal at the 2nd and 16th infantry division sectors respectively and advance to At-Tasa and Bir Al-Jifjafa. The aforementioned infantry divisions advance to At-Tasa.



3rd field army:

4th armored division crosses the canal at the 7th infantry division sector and, along with the 25th independent armored brigade, advance to Bir Al-Jifjafa.

7th infantry division advances through Al-Jidi Mountain Pass. Its brigades consolidate positions at both pass ends and east of Jabal Sahaba

19th infantry division advances through Mitla Mountain Pass. Its brigades consolidate positions at both pass ends and around Jabal Al-Hamma.

6th mechanized infantry division (with just its 113th mechanized infantry brigade) crosses the canal at the 19th infantry division sector, heads south towards the SW opening of Wadi Sudr, advances NE through the wadi and consolidate positions around Ras Al-Jundi.
